Motorsport Lithium Battery

The Super B Andrena 12V10Ah Lithium Battery is a 12V lithium iron phosphate battery, with a nominal capacity of 10Ah and energy of 128Wh for reliability, high performance and results. This battery is specifically designed for use in motorsport vehicles (cars and motorcycles), ATVs and jet skis.

Why Choose the Super B Andrena 12V10Ah Battery

The Andrena 12V10Ah equals a lead-acid battery of 20 to 32Ah, provided the alternator’s maximum current doesn’t exceed the battery’s maximum charge current of 37A. With high discharge capability, fast-charging and strong construction, combined with the minimal self-discharge rate, the battery life is long-lasting and quick to refill, ensuring that usage of the Super B Andrena 12V10Ah Lithium Battery is maximised. With lithium iron phosphate (LiFePO4) technology, combined with its waterproofness, it is the safest and most reliable battery on the market.

Lightweight Power

With a weight of only 1.7kg / 3.7lbs, the Andrena 12V10Ah power battery saves up to 80% in weight in comparison to traditional lead-acid batteries and is only 1/3 of the size of a conventional battery. This improves not only the performance of your vehicle but also helps to increase the fuel economy.

The power battery offers a high level of power, fast charging and a long, maintenance-free service life. It also has a stable and flat discharge, which means you have over 80% of the batteries capacity available, and you can leave your vehicle unattended for a much longer period compared to a lead-acid battery.

High-Performance

Fast charging in as little as 25 minutes minimises downtime, while a long cycle life of over 1,000 full discharges ensures reliable, maintenance-free performance. With a self-discharge rate of less than 3% per month, the battery holds its charge for extended periods, allowing vehicles to remain unattended much longer than with traditional lead-acid batteries.

Safe & Reliable

Due to its LiFePO4 technology, which is renowned for its thermal and chemical stability, the Super B Andrena Battery is amongst the safest lithium technologies on the market. As well as the technology, the Andrena Battery casing is made from PC-ABS with an ingress protection rating of IP69. These features make the battery completely dust-tight and waterproof, which is ideal for extreme motorsport environments.

3-Year Warranty

The Super B Andrena 12V10Ah Lithium Motorsport Battery comes with a 3-year manufacturer warranty and support from Aim Shop’s experienced technical team for your peace of mind. Super B provides batteries that have been engineered and tested against the harshest of environments to ensure high performance for years to come.

Super B Battery 3-Year Warrantee

Technical Information

Technical Specs

Electrical Specifications

  • Nominal Capacity: 10Ah
  • Energy: 128Wh
  • Nominal Voltage: 12.8V
  • Open Circuit Voltage: 13.2V
  • Self Discharge: <3% per month
  • Cycle life: >1000 (at 10C charge/discharge, 100% DoD)
  • EqPb (Equals lead-acid): 20 - 32Ah

Mechanical Specifications

  • Dimensions (LxWxH): 120 x 82 x 124mm / 4.72” x 3.23” x 4.88”
  • Weight: 1.7kg / 3.7lbs
  • Case Material: PC - ABS
  • Ingress Protection: IP69
  • Cell Type / Chemistry: Cylindrical - LiFePO4
  • EAN-13: 8718531360037
  • Battery Designation: 4IFpR27/66-4

Charge & Discharge Specifications

  • Charge Method: CCCV
  • Charge Voltage: 14.3V - 14.6V
  • Max Charge Current: 37A
  • End of Discharge Voltage: 8V
  • Discharge Current Continuous: 8160A
  • Discharge Pulse Current (1 sec): 493A (49C)

Temperature Specifications

  • Charge Temperature: 0°C to 45°C* / 32°F to 131°F*
  • Discharge Temperature: -20°C to 55°C / -4°F to 131°F
  • Storage Temperature: -20°C to 45°C / -4°F to 113°F

* Do not charge below 0°C / 32°F

Compliance Specifications

  • Certifications: CE, UN 38.3, UL 1642 (Cells)
  • Shipping Classification: UN 3480
